Features:
1. High conversion efficiency (energy efficiency VI)
2. Protection: OCP, OVP, OTP
3. EMC regulatory certification
4. RoHS&REACH
5. Support customized power supply
Output:
| Voltage |
9.0V-15.0V |
15.1V-21.0V |
21.1V-30.0V |
30.1V-40.0V |
40.1V-54.0V |
| Current |
0.01-7A |
0.01-5A |
0.01-4A |
0.01-2.8A |
0.01-2.1A |
| Power max |
90W |
90W |
96W |
100.8W |
100.8W |
Safety approvals
GB4943.1-2011, GB8898-2011, GB4706.1-2005 ,EN62368,1EC60950, EN61558, K60950,J62368 J61558,UL 62368,IS 13252, AS/NZS61558, AS/NZS62368.
EMC
GB17625.1-2012,GB/T9254- 2008,GB/T13837-2012,GB/T17625.1-2007,GB4343.1-2018,EN55032,EN55035, EN55014,EN61000,KN-32/35,FCC Part15
DC connector
