Input:
100-240VAC 50/60Hz 2.0A

Dimension:
98.5*46.8*30.7mm
Send inquiry
Product Parameters
Features:
1. High conversion efficiency (energy efficiency VI)
2. Protection: OCP, OVP, OTP
3. EMC regulatory certification
4. RoHS&REACH
5. Support customized power supply

Output:
Voltage 8.0-17.0V 17.1-27.0V 27.1-40.0V 40.1-55.0V
Current 0.01-4.25A 0.01-2.13A 0.01-1.41A 0.01-1.06A
Power max 51W 51W 51W 51W



Safety approvals
GB4943.1-2011, GB8898-2011,GB4706.1-2005, EN62368, IEC60950, EN61558,K60950,UL62368,UL60950,AS/NZS61558,AS/NZS60950, AS/NZS60065
EMC
GB17625.1-2012,GB/T9254- 2008,GB/T13837-2012,GB/T17625.1-2007,GB4343.1-2018,EN55032, EN55014, EN55024,EN61000,KN-32/35,FCC Part15

DC connector
