Features:
1. High conversion efficiency (energy efficiency VI)
2. Protection: OCP, OVP, OTP
3. EMC regulatory certification
4. RoHS&REACH
5. Support customized power supply
Output:
| Voltage |
9.0V-15.0V |
15.1V-21.0V |
21.1V-30.0V |
30.1V-40.0V |
40.1V-54.0V |
| Current |
0-7A |
0-5A |
0-4A |
0-2.8A |
0-2.1A |
| Power max |
96W |
96W |
96W |
100.8W |
100.8W |
Safety approvals
GB4943.1-2011,GB8898-2011 ,GB4706.1-2005,GB19510,EN61347,EN62368,IEC60950,EN61558,K60950,J61347,J62368,J61558,UL62368,AS/NZS61558,AS/NZS62368
EMC
GB17625.1-2012,GB/T9254- 2008,GB/T13837-2012,GB/T17625.1-2007,GB434-3.1-2018,EN55032,EN55035,EN61000,EN55014,KN-32/35,FCC Part15
DC connector
